"One-shot" and Continuous Auto-Focusing
New Auto Focusing
Auto-Focusing feature on digital microscope makes routine inspection faster and easier. The user can choose from continuous auto-focus, one-click auto-focus, or manual focus. By clicking any area of interest on the screen the camera will automatically focus within a fraction of second without manually moving the focus block up and down for tedious focusing. This new feature makes Revo HD cameras more ergonomic than ever before.
On-board measurement features
Measurement directly via HDMI
With the on-board ARM system, Revo AF is not only a superb imaging camera, but also a powerful measurement tool. This greatly extends the application areas of the HDMI camera. The measurement features including calibration, scale bar and al the other measurement features you can get by PC software.
60FPS@1080P
1080P 60fps Full Frame Rates
Guaranteed 60 fps at 1080p, Revo AF presents a perfect combination of outstanding resolution and frame rate, which allows the user to smoothly manipulate live images without any monitor lag.
HDMI FL imaging Capability
A well-rounded HDMI camera
Taking advantages of the ultra-high signal to noise ratio sensor, Revo AF allows you to set up to 10 seconds exposure time. The incredibly efficient 3D noise reduction performance delivers finest detailed images for low light fluorescence.
Live image stitching and EDF available on new PC software
2 new technologies
“Real-time” image stitching: It generates large-sized mosaic images in a few seconds while moving the stage, which is light, smooth and worry-free!
Built- in Mouse Control Camera
No PC needed.
With the built-in application software inside the camera. The user can control the camera with just a mouse. There is no need for a PC.
| Item# | Revo AF |
|---|---|
| Warranty | 1 YEAR |
| Software Support | 3 Months |
| Sensor | SONY IMX291 |
| Resolution | 2.0 megapixels |
| FPS @ Max Res(USB) | 30 @ 1920 x 1080 |
| FPS @ Max Res(HDMI) | 60 @ 1920 x 1080 |
| Camera Interface | USB 2.0, HDMI |
| White Balance | Automatic, Manual |
| Driver API Compatibility | DirectX |
| File Formats | BMP |
| Exposure Control | Automatic |
| Exposure Time | 0.4ms – 999ms |
| Supported Operating Systems | Windows 10, Windows 8, Windows 7, Windows Vista |
| System Requirements | 2GB RAM Recommended, 2Ghz+ CPU Recommended, USB 2.0 High Speed Port |
| Power Source | External Power Supply |
